Product Description
The CONBRACO 70-245-01 is a 2-piece standard ball valve designed for soft soldering into lines without disassembly. It features a bronze body, a steel handle with a vinyl grip, and a 316 stainless steel stem and trim. This valve is suitable for general-purpose applications with gas and water media.
- Compression (Solder) connection type
- Bronze body material
- Lever handle operator type
Product Highlights
The CONBRACO 70-245-01 ball valve offers reliable performance with its robust construction and premium materials.
Product Information
Standard Information
- Brand: CONBRACO
- Manufacturer Part Number: 70-245-01
- Country of Origin: USA
Technical Specifications
- Series/Model: Series 70-240
- Nominal Size: 1 IN
- Connection Type: Compression (Solder)
- Pressure Rating: 600 PSI (CWP), 150 PSI (SWP)
- Temperature Rating: Up To 500 DEG F
- Opening Size: 0.87 IN
- Body Material: Bronze
- Operator Type: Lever Handle
- Handle Material: Steel With Vinyl Grip
- Stem Material: 316 Stainless Steel
- Trim Material: 316 Stainless Steel Ball
- Packing Material: MPTFE Stem
- Seat Material: RPTFE
- Seal Material: PTFE
- Material Standard: Body: ASTM B584
- Material Specification: UNS C84400
- Industry Standards: MSS-SP-110 Compliant, CSA B51, CRN: OC10908.5C
- Width: 4.5 IN
- Lead Free: No
- Flow Co-Efficient (Cv): 43
- Actuator Type: Lever
- Ball Material: 316 Stainless Steel
- Domestic/Import: Domestic
- Media: Gas, Water
- Port Type: Standard
- Inlet to Outlet Length: 4.5 in
- Top to Inlet Center: 2.25 in
- End Style: solder
- Softgoods Material: PTFE/MPTFE
- Manufacturer: Apollo Conbraco
- Manufacturer #: 70-245-01
- Type: 2-Piece
